Saince Merge eFilm Workstation is a stand-alone workstation solution to view, distribute and manage studies. eFilm Workstation allows users to have a full diagnostic quality workstation, dedicated CD/DVD burning, DICOM printing and an image review station in a low cost and high content solution that is scalable to any organization.

.

PET/CT Image Display

.
Fused PET and CT images from the same study can be viewed, permitting visualization of functional PET data combined with anatomical CT data.
.

Pixel-for-Pixel Zoom

.
Provides the option to display the image at full resolution with no interpolation.
.

True-sized Printing

.
User can specify a scale factor that will result in true-sized DICOM printing, needed for orthopedic templating when using acetate templates.
.

MPR

.
  • MPR Reconstruct a cross-sectional image in any plane from CT or MR data
  • View real-time reconstruction in any orthogonal or oblique plane with exquisite image quality
  • Use MPR plane to generate slabs of arbitrary thickness via MIP
  • Automatically creates a new series
  • Stack through the reformatted images as you would any other series; view each slice’s relative position on the source image
.

User Profiles

.
  • Create unique user profiles based on user name
  • Save multiple user profiles on a given workstation to allow users to easily launch their preferred toolbar configurations, window and level presets, layout presets and more
.

3D/Volume Rendering

.
  • 3D/Volume Rendering Preview slices and select particular images for inclusion (or exclusion) from volume reconstruction
  • Adjust interpolation to suit processor speeds
  • Color mapping opacity setting options
  • View structures or organs as a whole (versus slices)
  • IMPORTANT: To support optimal clinical visualization, the user must deploy a color monitor and a video card that fully supports Microsoft DirectX 8.1 or greater. In the absence of the DirectX 8.1 video card, Volume Rendering functionality and performance will be lower than optimal.
.

DICOM Printing

.
  • Print to a large variety of printers
  • Send a manufacturer-specific string to the printer, via the DICOM print configuration, for specifying a particular Look Up Table at the printer
.

Customizable Toolbars

.
  • Customizable Toolbars Display only the tools needed when viewing various types of studies such as CR or MR
  • Access needed tools quickly for increased efficiency
  • Change the size of the icons on screen
  • Invoke auto-hide feature to hide tools when not actively using them, maximizing use of diagnostic screen space
  • Set up keystroke combinations to perform toolbar functions
.

Integrated CD & DVD Creation

.
  • Burn CDs or DVDs directly from the eFilm Workstation application
  • Burn a ‘lite’ version CD or DVD of eFilm Workstation to use as a portable viewer using the integrated DICOMDIR support feature
  • Compliant with IHE Portable Data Interchange (PDI)
  • Burn non DICOM Files to CD, and DVDs
.

Intuitive GUI

.
  • Customize toolbars per modality
  • Save user settings in a user profile
  • Work more accurately with dynamic distance display, mouse-over recognition and an alternating color scheme that make measurement lines much easier to read
.

Mouse Support

.
  • Accelerate productivity with a mouse configuration that allows users to use a variety of mouse hardware
  • Assign right and left mouse click functions to different mouse or trackball buttons
  • “Lock” a mouse or trackball button for common operations such as stacking and windowing; once the button is locked, the operation can be performed without requiring sustained button depression
.

New with eFilm Workstation 4.2.2

.
  • 4.2.2 Includes many minor fixes to improve performance for faster image scrolling
  • Embedded iConnect Cloud Archive (formerly Merge Honeycomb) Integration for available remote archiving and web distribution of studies
  • Auto-routing of studies included
  • Image compression when sending studies
  • Ability to connect to other efilm 4.X workstations securely without a VPN
  • Gray Scale Presentation State (GSPS) support for Key Images
  • SUV for PET/CT Included
.
